Energy efficiency specifications

on the nameplate

− IE classification with numerical value of efficiency during line operation for 50 and 60 Hz

− USA: ee label (by DoE, Department of Energy, EISA 2007)

− Canada: CSA (Energy Verified) label (EER 2010)

− China: CEL label (GB 18613)

− Brazil: ENCE label

− South Korea: KEL label according to REELS

Additional information on the nameplate

− According to US design specification NEMA MG1

- TEFC, TEBC, TENV depending on ventilation type

- K.V.A. code, code letter of the short circuit apparent power

- M.L. (Mounting Location), four-digit code for UL-registered mounting location

- Design code, code letters for startup and breakdown torque and starting

− Temperature range, according to the Canadian design specification CSA C22.2, SEW-EURODRIVE approval up to + 40°C, efficiency level to CSA C390, specifications for operation on a frequency inverter

− Conformity and certification logo for

- Europe: CE label

- USA: UR marking

- Canada: CSA label

- China: CCC label, if necessary

- EAC: Eurasian conformity

Further information

Also observe the DR…J motor designs for IE2, IE3, and IE4 (LSPM technology on pages 130 + 131). Observe the changes in regulation 640/2009 for Europe and other planned changes of the energy efficiency laws/regulations after January 1, 2015.
