DR.. series AC motors
Standard AC motors
in efficiency classes IE1 to IE4
Features – DR.. motors comply with all global standards that are based on IEC 60034
– Independent of the required energy efficiency class, the whole range of DR.. motor options or variants is available for all efficiency classes
– The new modular DR.. motor system series offers:
- The four energy-efficient motor designs IE1, IE2, IE3 and IE4 according to IEC 60034-30-1
- A perfect brake concept, i.e. up to three different brake sizes for each motor size
- Cost-efficient built-in encoders integrated in the motor
- Significant time savings thanks to optimized motor selection, ordering, and logistics processes
IE class | Number of poles | Motor type | With 50 Hz frequency | With 60 Hz and 50/60 Hz frequency | |
Power rating kW | Power rating kW | Power rating hp | |||
Without IE classification | 2-pole | DR63.. | 0.18 – 0.37 | 0.18 – 0.37 (60 Hz) | 0.25 – 0.5 |
4-pole | DT56.. / DR63.. | 0.09 – 0.25 | 0.09 – 0.25 (60 Hz) | 0.1 – 0.34 | |
6-pole | DR63.. | 0.09– 0.18 | 0.09 – 0.18 (60 Hz) | 0.1 – 0.25 | |
IE1 | 2-pole | DRS.. Sizes 71 – 315 | 0.37 – 9.2 | 0.37 – 9.2 | 0.5 – 12.5 |
4-pole | 0.18 – 200 | 0.18 – 225 | 0.25 – 300 | ||
6-pole | 0.18 – 7.5 | 0.18 – 7.5 | 0.25 – 10 | ||
IE2 | 2-pole | DRE.. Sizes 71 – 315 | 0.75 – 9.2 | 0.75 – 7.5 | 1 – 10 |
4-pole | 0.25 – 200 | 0.25 – 225 | 0.34 – 300 | ||
6-pole | 0.25 – 5.5 | 0.75 – 5.5 | 1 – 7.5 | ||
IE3 | 2-pole | DRN..* Sizes 80 – 132 | 0.75 – 7.5 | 0.75 – 7.5 | 1 – 10 |
4-pole | DRN.. Sizes 80 – 315 | 0.75 – 200 | 0.75 – 200 | 1 – 275 | |
6-pole | DRN..* Sizes 90 – 160 | 0.75 – 7.5 | 0.75 – 7.5 | 1 – 10 | |
IE4 | 4-pole | DRU...J Sizes 71 – 100 | 0.18 – 3 | – | – |
* In preparation
