DR.. series AC motors

Voltages and energy efficiency classes that differ around the world, but nevertheless just one motor

03 The

GLOBAL MOTOR

for global players

Features – With the 50/60 Hz specifications and the inclusion of the elements that are typically required for a country on the nameplate, motors of the DRS.., DRE.. and NEW DRN.. series offer the unique possibility of unifying many different designs in one drive

– Thanks to its large voltage range, it is possible to achieve the different voltages anywhere in the world with one motor

– This “global motor” of SEW-EURODRIVE complies with various international standards, especially IEC EN 60034, NEMA MG1, CSA C22.2, ABNT, NCh 3086 and to the energy efficiency regulati- ons in Europe: Directive 2009/125/EC (ErP), USA: EISA 2007, Canada: EER, Brazil: PN 553, China: GB 18613

– Significant time savings thanks to optimized processes in motor selection, order processing, and logistics

Voltage range DRS../DRE.. motors

220 – 242 / 380 – 420 V

or

380 – 420 / 660 – 725 V

254 – 277 / 440 – 480 V

or

440 – 480 V

Voltage range

NEW: DRN.. motors

220 – 230 / 380 – 400 V

or

380 – 400 / 660 – 690 V

254 – 260 / 440 – 460 V

or

440 – 460 V

Frequency 50 Hz 60 Hz

Power 4-pole:

DRS..: 0.18 kW (0.25 hp) – 0.55 kW (0.75 hp)

DRE.. 0.75 kW (1.0 hp) – 5.5 kW (7.5 hp)

NEW DRN..: 0.75 kW (1.0 hp) – 200 kW (275 hp)

Also 2-pole and 6-pole motors are available in the „global motor“ design. Feel free to contact us.

The regulations of many countries have exceptions for gearmotors, brakemotors and Ex motors among others. For detailed and up-to-date information, refer to www.ie-guide.com/en/ieguide
