CH WORM GEARED MOTORS AND WORM GEAR UNITS
The new CH worm gearboxes of Chiaravalli Group S.p.A. have been produced to satisfy the market that require a product in dimensions and construction without changing the existing drawings and to guarantee non stop of their spare parts.
Chiaravalli Group S.p.A. designed this new product by improving and introducing better technical modifications to offer easier application of the groups to the different assembling configurations so that by offering a better service in flexibility and delivery time.
Starting from these considerations, we have a gearbox with a motor mounting flange that is separable from the housing which incorporate the oil seal; in this way we avoid any risk of damaging the oil seal in case of replacement of the input flange and the O-Ring can be eliminated.
All the aside covers, swinging and with feet, have O-Rings instead of traditional flat gaskets. The sizes 03-04-05 allow the rotation of the feet without disassembling them; furthermore the versions with swinging aside covers allow the lateral flanges to be fitted on both sides with simple fixing screws.
The worm screw has a ZI involute profile: with this worm-wheel coupling we shall get a better performance with a temperature reduction.
The gearboxes and motors are painted with RAL 9022 aluminium colour epoxy powder to protect the parts from oxidation and against micro-blowholes that can come during the pressure of die-castings.
The CHPC pre-stage gears (already present in the catalogue of CHM) can also be mounted with this range, obtaining a gear ratio up to 1:300.
For bigger reductions is possible to have two gears together using an appropriate kit.
LUBRICATION 59MOTOR MOUNTING FLANGESFEET ROTATIONCH 03/04/05 WORM GEARED MOTORS AND WORM GEAR UNITS CH... CHE... ORDER EXAMPLECH 03/04/05 MOUNTING POSITIONB3 B6 V5B3 A P V 55PF1CH 04 - PERFORMANCE WITH 4-POLE MOTORS 1400 REVS. INPUT DIMENSIONS A PVNPFA1A 82V 82PF1PFA1CH 06/07/08 WORM GEARED MOTORS AND WORM GEAR UNITS CH.. CHE.. MOUNTING POSITIONB3 B6 V5CH06FC 1 CH06FC 2 DIMENSIONS CH07FC 1 CH07FC 2CH07FE1 CH07FE2 DIMENSIONS CH08FC 1 CH08FC 2CH08F1 CH08F2CHR 03-04-05 CHR 06-07-08CHRE 03-04-05 CHRE 06-07-08OUTPUT SHAFT DIMENSIONSCHPC/CH - PERFORMANCE WITH 4-POLE MOTORS 1400 REVS. INPUTCHPC.. /CH 06-07-08CHPC.. /CH 04-05 DIMENSIONS OF CH/CH COMBINED GEARS CH 03/CH 04-05 CH 03/CH 06 CH 04/CH 07-08ORDER EXAMPLEOADVASCH - CH PERFORMANCE WITH 4-POLE MOTORS 1400 REVS. INPUTDIMENSIONS OF CH/CH COMBINED GEARSCH 03/CH 04-05 CH 03/CH 06 CH 04/CH 07-08SINGLE OUTPUT SHAFT KITDOUBLE OUTPUT SHAFT KITCH 03-04-05 CH 06-07-08REDUCTION BUSHINGS KITCH - USE AND MAINTENANCE INSTRUCTIONS
