CHPC/CH - PERFORMANCE WITH 4-POLE MOTORS 1400 REVS. INPUT
TYPE i=ratio n2 r/min Kw=P1 Nm=T2
105 13.3 0.12 42
138 10.1 0.12 42
TYPE i=ratio n2 r/min Kw=P1 Nm=T2
108 12.9 0.18 72
135 10.4 0.18 85
CHPC63
CH 04
180 7.8 0.12 46
210 6.7 0.12 40
300 4.7 0.12 36
CHPC63
CH 05
180 7.8 0.12 65
210 6.7 0.12 67
240 5.8 0.12 58
300 4.7 0.12 56
TYPE i=ratio n2 r/min Kw=P1 Nm=T2
TYPE i=ratio n2 r/min Kw=P1 Nm=T2
CHPC71
CH 05
84 16.7 0.25 80
108 12.9 0.25 90
135 10.4 0.25 90
CHPC71
114 12.3 0.37 170
135 10.4 0.37 176
192 7.3 0.25 149
TYPE i=ratio n2 r/min Kw=P1 Nm=T2
120 11.7 0.55 280
CH 06
240 5.8 0.25 130
300 4.7 0.25 120
CHPC71
150 9.3 0.37 215
180 7.8 0.37 235
TYPE i=ratio n2 r/min Kw=P1 Nm=T2
CH 07
240 5.8 0.37 210
300 4.7 0.25 275
CHPC80
CH 07
90 15.6 0.75 310
120 11.7 0.75 300
150 9.3 0.55 260
TYPE i=ratio n2 r/min Kw=P1 Nm=T2
168 8.3 0.55 350
TYPE i=ratio n2 r/min Kw=P1 Nm=T2
CHPC71
CH 08
192 7.3 0.37 280
240 5.8 0.37 290
300 4.7 0.37 275
CHPC80
CH 08
120 11.7 0.75 390
138 10.1 0.75 360
168 8.3 0.55 350
192 7.3 0.55 330
240 5.8 0.55 305
76 DIMENSIONS
