MOVI-SWITCH motor starter
Features – Gearmotor with switching and protection function integrated in the motor terminal box
– 2-, 4- and 6-pole
– Power range 0.09 to 3.0 kW
Ú For more information regarding
– MOVI-SWITCH: Page 202 06
– Fieldbus interfaces, field distributors, cable systems: Page 190
6.3 Decentralized installation: Motor starters
MOVIFIT SC motor starter
Features | – Electronic (contactless) motor starter with one or two directions of rotation – Parameterizable soft startup time – Integrated brake management – Increased safety through switching of 3 phases – Integrated power distribution with line protection up to 6 mm² – Optional maintenance switch – CAN/SBus interface for external components – Free programming according to IEC 61131 – Integrated parameter memory – Comprehensive diagnostics via LEDs – Expanded parameterization and diagnostics via MOVITOOLS MotionStudio or fieldbus – Robust aluminum housing – Degree of protection IP65 (optional IP69K) – Approval: , and – Optional HygienicPLUS design, i.a. degree of protection IP69K |
Technical data | Power range – When connecting 2 motors (dual-motor starter) i one direction of rotation: 0.37 kW – 1.5 kW each – When connecting 1 motor (reversing starter) i two directions of rotation: 0.37 kW – 3.0 kW each Voltage range 3× AC 380 V – 500 V / 50 Hz to 60 Hz Digital inputs/outputs – 6 DI + 2 DI/O with function level Classic – 12 DI + 4 DI/O with function level Classic and PROFINET fieldbus – 12 DI + 4 DI/O with function level Technology |
Communication | PROFIBUS, PROFINET, PROFIsafe, DeviceNet™, EtherNet/IP™ and Modbus/TCP, PROFINET interface SCRJ / POF |
Connection variants | Motor starter consists of EBOX = electronics unit and ABOX = connection box: – MOVIFIT standard connection box: via cable glands – MOVIFIT hybrid connection box: with variable connector configuration |
MOVIFIT function level
Indicates the functional level of the software assigned to the MOVIFIT units regarding
– Operation
– Local system control
– Diagnostics
Classic Simple functions | Technology Free programming (MOVI-PLC/MOVITOOLS MotionStudio) |
– “Easy mode”: Easy startup via DIP switches possible – Standardized drive functions – Control as fieldbus gateway – Extended configuration and diagnostics options via gateway configurator | – Programming in accordance with IEC 61131 (e. g. in FBD, LD, IL, ST, SFC) – MOVITOOLS MotionStudio with PLC Editor, Application Builder, etc. – Multi-level library concept (application and program modules of the MOVI-PLC controller series) – Decentralized processing of digital inputs and outputs in the software |
