safety
Functional safety
– FS safety-rated BE.. brake (FS02) in horizontal operation up to PL d and in vertical operation up to PL c in ac- cordance with EN ISO 13849-1 with indication of the size
– NEW: Static and dynamic brake diagnostics for MOVI-PLC in addition to the brake
– Safety functions of our brakes
- SBC (safe brake control)
- SBA (safe brake actuation)
- SBH (safe brake hold)
NEW: BF../BT.. double brake for DR.. motors
The brake of your choice – Brake combination options 03
Motor type | Brake type | Winsp 106J | Braking torque steps Nm | |||||||||
DR.112/132 | BF11 BT11 | 2×285 2×190 | 2×20 | 2×28 | 2×40 | 2×55 | 2×80 | 2×110 | ||||
DR.160 | BF20 BT20 | 2×445 2×300 | 2×40 | 2×55 | 2×80 | 2×110 | 2×150 | 2×200 | ||||
DR.180 | BF30 BT30 | 2×670 2×450 | 2×75 | 2×100 | 2×150 | 2×200 | 2×300 | |||||
Brake combination options
The DR.. motor can be combined with the BF../BT.. brake that is ideal for your application to match its requirements for the braking torque or braking work. For design reasons, the motors with double brake from SEW-EURODRIVE are very compact.
The double brake can be used in dusty environments with or without „functional safety“. An extremely low-nose BT.. design with functional safety is available to meet the requirements of entertainment technology.
NEW: The BF../BT.. double brake can be equipped with the contactless DUE.. function and wear monitoring. It constantly shows
– the current switching state or if the wear limit is reached and
– it transmits the current air gap.
