Explosion-proof motors
EDR.. series to HazLoc-NA (Hazardous Locations North America)
Features – EDRE.. and EDRN.. motors not only meet the requirements of energy efficiency class IE2 and IE3 according to IEC 60034-30-1 but also comply with EISA 2007 and CSA C390-10 for the North American market and thus meet the requirements of many countries that accept these stan- dards.
– The motors are certified according to the Class Division System and thus meet the requirements of the explosion protection regulation on the North American market and the basic standards CSA 22.2 and NEC 500
– Available as gearmotor/motor, /CID2 type, for division 2 class I for gas groups A, B, C and D
– Available as gearmotor/motor, /CIID2 type, division 2 class II for dust groups F and G
– Available as gearmotor/motor, /CICIID2 type, for division 2 class I for gas groups A, B, C and D and Class II for dust groups F and G
– Also available as brakemotor with latch function
– SEW-EURODRIVE is certified to UL and CSA
– Operation on frequency inverter, also in field weakening range operation, possible in both classes
– Same compact and performance-oriented characteristics as the standard drives
– Motors also possible with ATEX gear units (EU Directive 2014/34/EU) on request
Division 2 | Type 4-pole | IE class | Power range in kW |
Class I | EDRS 71 – 80 | IE1 | 0.18 – 0.55 |
Groups A, B, C, and D | EDRE 80 – 225 | High (IE2) | 0.75 – 45 |
T3 with operation on frequency inverter | EDRN 80 – 280 | Premium (IE3) | 0.75 – 90 |
T3C with operation on supply system | EDRN 315* | Premium (IE3) | 110 – 200 |
T3B/C brakemotor on supply system | |||
Class II | |||
Groups F and G |
* In preparation
