DRM.. torque motors
DR.. series: DRM.. design
Features The DRM.. design (product designation „torque motor“) is a 12-pole motor that can be opera- ted continuously and thermally safely on a 3-phase system even when the rotor is blocked. Every torque motor is available with three rated torques.
This allows for the manifold requirements of various applications to be easily met
– Many additional features of the AC motor modular system are available
– Can be combined with the 7-series of the modular gear unit system from SEW-EURODRIVE
Standstill torque, Rating 1 M0 Nm | 0.7 – 3.6 / 50 Hz 0.6 – 2.7 / 60 Hz |
Cyclic duration factor Rating 1 | S1, continuous duty |
Standstill torque, Rating 2 M0 Nm | 2.6 – 17.3 / 50 Hz 2.1 – 12.2 / 60 Hz |
Cyclic duration factor Rating 2 | S3/15%, intermittent duty with a cyclic duration factor of 15% |
Standstill torque, Rating 3 M0 Nm | 1.9 – 8.7 / 50 Hz 5.9 / 60 Hz |
Cyclic duration factor Rating 3 | S1, continuous duty with forced cooling fan |
Sizes 71 – 132
Lengths S, M, L
Frequency Hz 50, 60
DRK.. single-phase motors
NEW: DR.. series: DRK.. design
03
Features | The DRK.. design design can be used in 1× 230 or 1× 220 V single-phase supply systems. The running capacitor installed in the terminal box allows for operation under many demanding ambient conditions. SEW-EURODRIVE also offers the ET56 and the ER63. | ||
Sizes | Power rating kW | Frequency Hz | Energy efficiency class1) |
DRK71S4 | 0.18 | 50 or 60 | IE1 |
DRK71M4 | 0.25 | IE1 | |
DRK80S4 | 0.37 | IE1 | |
DRK80M4 | 0.55 | IE1 | |
DRK90M4 | 0.75 | IE1 | |
DRK90L4 | 1.1 | IE1 | |
ET56 | 90 watts | With running capacitor | |
ER63 | 90 / 120 / 180 watts | Without capacitor | |
1) according to IEC 60034-30-1
