Options for servo gear units
Direct motor mounting | Positive direct motor mounting (without terminal adapter) of the SEW-EURODRIVE servomotor series CMP.. and CM.. |
Motor adapter | EPH motor adapter for PS.F and PS.C planetary servo gear units, ECH motor adapter for PS.C planetary servo gear units and EBH motor adapter for BS.F helical-bevel servo gear units |
Reduced backlash | Optionally for PS.F planetary servo gear units and BS.F helical-bevel servo gear units with significantly smaller rotational clearance |
Minimized rotational clearance | Optionally for PS.F planetary servo gear units with even more reduced rotational clearance |
7.2 Explosion-proof servo gear units
Servo gear units
Certified gear units | Certified protection types | |
PS.F planetary servo gear units | – For the European market: Gear units comply with directive 2014/34/EU (ATEX), equipment group II, equipment category 2, II2GD design – Also accepted in China – Comply with TR CU, the Eurasian Custom Union Russia/Belarus/Kazakhstan/Armenia in combination with Ex EAC certificate (suc- cessor to GOST-R) | – Protection type “c”: Protected by safe construction (design safety) EN 13463-1 and -5 – Protection type “k”: Protected by liquid immersion, EN13463-1 and -8 |
BS.F helical-bevel servo gear units |
07
7.3 Accessories and options: Gear units
Corrosion protection (KS) and surface protection (OS)
for all standard gear units
Features | To protect motors and gear units that are subject to severe environmental influences, SEW-EURODRIVE offers possibilities to increase the resistance of highly stressed surfaces. |
KS corrosion protection | Measures to increase the resistance to corrosion: – All retaining screws that are loosened during inspection or maintenance work are made of stainless steel – Nameplates are made of stainless steel and various motor parts are coated with a finishing varnish – The flange contact surfaces and shaft ends are treated with a temporary rust preventive – In addition, clamping straps are used for brakemotors |
OS surface protection | In addition to the standard surface protection, motors and gear units are optionally available with surface protection OS1, OS2, OS3 or OS4. This makes the gearmotors well equipped for operation under various ambient conditions. |
Measures for interior treatment and standard parts
Special interior surface coating
Rustproof nameplates
RS bearing for IP56
Special interior surface coating
Brakes with pressure plate made of non- corrosive material
Non-corrosive retaining parts
Special interior surface coating
Rustproof breather valves
NOCO fluid, the contact corrosion
inhibitor Output shaft made
of stainless steel
Optional coating at drive shaft end (in the area of the radial oil seal seat)
