– Energy efficiency in servo applications
Features The crucial part of energy-efficient operation of servo drive technology is the detailed planning and fulfilment of process and efficiency requirements. With the energy efficiency concept effiDRIVE for servo applications, SEW-EURODRIVE offers comprehensive consulting during the planning of new plants and the modernization of existing systems. With our great expertise regarding drive tech- nology and the industry, we focus on efficiency already during the first steps of selecting the used technology and products in order to optimize the energy consumption. But it is not sufficient to only combine energy-efficient components. Only looking at the application in its entirety allows for the maximum energy efficiency.
Energy-efficient components
Sine-shaped regenerative power supply modules MXR80A | – In regenerative operating states, the braking energy is fed back into the supply system – Energy supply and energy recovery are sinusoidal with cos φ = 1 – Almost complete avoidance of supply harmonics – No interference of sensitive electronic devices in direct vicinity – Determination of energy flow, detailed diagnostic information – Controlled DC link voltage independent of link voltage |
Block-shaped regenerative power supply modules MXR81A | – In regenerative operating states, the braking energy is fed back into the supply system – Inexpensive alternative to sinusoidal regenerative power supply if the supply system conditions are stable – Automatic deactivation of the recovery during motoring operation – Emergency braking resistor can be connected |
Capacitor module MXC80A | – DC link energy is absorbed or supplied with up to 50 kW – Up to 1000 W can be stored in the module – The module is charged actively via charging connection – With adequate project planning, the braking energy can be completely recycled for the next travel task – There is no need for braking resistors – Especially suited for cycles with small drives |
Compact power supply module MXP81A | – Combination of 10 kW power supply module and 250 W capacitor module – Especially cost-effective and space-saving with small systems – Size-optimized braking resistor is already integrated in the module |
06
6.2 Wall mounting
MOVI4R-U basic inverters
MOVI4R-U in IP54
Features | – Optimum solution to fulfill the basic requirements in drive technology: simple speed control of asynchronous motors – Intuitive operating concept for short startup times and simple handling – High degree of protection IP54 – Modular design for quick unit replacement – Fast and simple exchange of the power section in service cases – Guaranteed integration into recycling systems | |
Line connection | Power range in kW | |
1-phase / 220 – 240 V | 0.25 – 0.55 | |
3-phase / 220 – 240 V | 0.25 – 0.55 | |
3-phase / 380 – 500 V | 0.25 – 1.1 | |
Configuration | – Frequency inverter with V/f control – Control plate with control knob as combination of adjusting knob and push button – Control and setpoint selection: - with digital inputs and fixed setpoints - setpoint selection with analog input - manual mode with control plate | |
Options | NF003.. und NF008.. | HD.. |
Line filter combined with a main switch − Facilitates EMC-compliant installation − Switch off the inverter individually during maintenance work | Output filter − to suppress magnetization noises at the motor − to improve cable losses and for long motor cables | |
Sustainable product life cycle of
A
S
E
1
P
H
A
S
A
S
E
4
P
H
MOVI4RU for optimum conservation of resources
A
H
P
E
2
P
H
3
E
S
06
Phase 1 Development
– Choice of environmentally friendly materials
– Low material and raw material intensity
– Reduced material diversity, simple separability
Phase 2 Manufacturing
– Resource-efficient production and logistics concepts
– Use of renewable energies
– Low transport intensity thanks to local production
– Environment-friendly manufacturing processes
Phase 3 Use
– High energy efficiency of the operating phase
– Optimized product life: durable, maintenance-friendly, expandable
– Options for technical upgrades (without having to replace the entire unit)
– effiDRIVE energy saving consultation for support
Phase 4
Re-integration
– Design that is suitable for recycling
– Re-integration and recycling of components in material and raw material cycles
– Environmentally sound waste disposal
Recycling processes: Today‘s products are tomorrow‘s raw materials: We are happy to arrange a homogenous separation and correct re-integration of the materials used in the MOVI4R-U in the material cycles – feel free to contact us!
The basic inverter has been scientifically tested in a life-cycle assessment study carried out by the Institute for Industrial Ecology of the Pforzheim University.
MOVI4R-U achieved first successes and won the “Nachhaltige Produktion Award 2014” (sustainable production award) at the “Industrial Green-Tech-Conference” at the HANNOVER MESSE 2014.
