MATERIAL L
K
Galvanized metal sheet FE 430
SW
B
N
P
K
S
30 E
E | |
V |
C
C H
M mm
DIMENSIONS
MOTOR TYPE CODE L B H Mmin G E J K C N P SW S SIZE
63/80 210 90100210 210 195 33 100 70 20 25 50 10,5 43 98 19 3
63/112 270 90100270 270 195 33 100 70 20 25 50 10,5 43 98 19 3
100/160 430 90100430 460 290 40 140 95 27 29 62,5 12,5 90 165 22 4
90/132 340 90100340 340 290 40 135 95 27 29 62,5 12,5 90 165 22 4
160/180 490 90100490 490 410 40 254 95 40 30 60 15 193 142/284 22 4
ADJUSTMENT WIDENESS
TYPE 63 71 80 90 100 112 132 160 180 WEIGHT kg
270 130 118 105 90 70 40 2,8
210 70 58 45 2,2
430 216 186 10 122 7,5
340 140 130 100 75 6,7
490 156 131 10,8
161
BELT TENSIONER SLIDES FOR ELECTRIC MOTORS
