IE 2 EFFICIENCY MOTORS

< Previous Chiaravalli Gearboxes and Motors | Products index | Next Chiaravalli Gearboxes and Motors >

IE 2 EFFICIENCY MOTORS

Starting from June 2011, 2 - 4 - 6 poles electric motors with power included from 0,75kw to 375kw. sold into European Community, must be in accordance with EU MEPS European Union Minimum Energy Performance Standards regulation concerning efficiency level, in order to reduce consumptions and C02 emissions.

IE 2 mark reported on the motors nameplate will show that it belongs to this class.

TYPE			POLES	POWER Kw	VOLTAGE V	CURRENT 400 V	TORQUE N/m	EFFICIENCY %	FACTOR COS.ø	WEIGHT Kg.
	CHT 80	A2	2	0.75	230/400	1.75	2.51	77.40	0.80	9.10
	CHT 80	B2	2	1.10	230/400	2.45	3.69	80.00	0.82	10.70
	CHT 80	C2	2	1.50	230/400	3.12	4.97	82.70	0.83	13.00
CHT 80		B4	4	0.75	230/400	1.79	5.04	79.60	0.76	11.20
	CHT 80	C4	4	1.10	230/400	2.72	7.39	81.40	0.71	13.50
	CHT 90	S2	2	1.50	230/400	3.20	4.95	81.40	0.83	13.30
	CHT 90	L2	2	2.20	230/400	4.54	7.38	83.20	0.84	16.00
	CHT 90	S4	4	1.10	230/400	2.50	7.37	81.40	0.78	13.90
	CHT 90	L4	4	1.50	230/400	3.31	10.09	82.80	0.79	16.20
	CHT 90	M4	4	2.20	230/400	5.09	14.71	84.30	0.74	20.50
	CHT 90	S6	6	0.75	230/400	2.01	7.66	76.00	0.71	13.00
	CHT 90	L6	6	1.10	230/400	2.82	11.23	78.10	0.72	16.30
CHT 100		LA2	2	3.00	230/400	5.88	10.05	84.60	0.87	23.00
	CHT 100	LA4	4	2.20	230/400	4.83	14.70	84.30	0.78	22.70
	CHT 100	LB4	4	3.00	230/400	6.33	20.00	85.50	0.80	26.50
	CHT 100	LA6	6	1.50	230/400	3.71	15.20	80.00	0.73	22.00
	CHT 112	M2	2	4.00	230/400	7.56	13.13	86.00	0.89	27.00
CHT 112		M4	4	4.00	230/400	8.23	26.60	86.60	0.81	32.50
	CHT 112	L4	4	5.50	230/400	11.25	36.57	87.90	0.80	39.00
	CHT 112	M6	6	2.20	230/400	5.17	22.30	81.80	0.75	29.50
	CHT 132	SA2	2	5.50	230/400	10.25	18.00	87.20	0.89	40.20
	CHT 132	SB2	2	7.50	230/400	13.80	24.47	88.10	0.89	45.00
	CHT 132	S4	4	5.50	230/400	11.00	36.22	87.90	0.83	44.00
	CHT 132	M4	4	7.50	230/400	14.50	50.00	88.70	0.84	53.50
	CHT 132	M6	6	4.00	230/400	8.86	40.42	84.60	0.77	45.00
	CHT 132	S6	6	3.00	230/400	6.84	30.48	83.30	0.76	36.10

157

ELECTRIC MOTORS 2/4/6 POLES - IE2

* Motors size 160 up to 355 on request

* Volt 400/690 standard from 160 up to 355 on request for other sizes.

* ABB motor available on request

* MGM brake motor available on request

b L

S d
