POSITION DIAGRAM FOR OUTPUT

FA1, FB1, FC1, FD1, FE1 FA2, FB2, FC2, FD2, FE2

Unless specified otherwise, the reduction unit is supplied with the flange in pos. F..1 referred to position B3.
