Type designation

Keypad

– FBG11B

– DBG60B

Standard keypads for parameterization, data management, startup, and diagnostics:

– Pluggable basic keypad

– Plain text keypad

Parameter module UBP11A

Simple data backup with the possibility of serial startup

Communication modules

– FSC11B / FSC12B

– FSE24B

– SBus / RS485 / CANopen

– EtherCAT

Fieldbus connection

– PROFINET IO

– DFE32B

– DFE33B

– Modbus TCP / EtherNet/IPTM

– DFE24B

– EtherCAT

– DFP21B

– PROFIBUS DPV1

– DFD11B

– DeviceNetTM (CANopen integrated in basic unit)

Extension for inputs and outputs

– FI011B

– FI021B

– Analog module with setpoint input, analog output and RS485 interface

– Digital module with 7 digital inputs and SBus connection

Setpoint adjuster MBG11A

Remote speed control in the range of -100% to +100%

Interface adapter

– UWS11A / UWS21B

– USB11A

– Signal conversion from RS232 to RS485

– Signal conversion from USB to RS485

Safe communication

– DFS11B

– DFS21B

– PROFIsafe via PROFIBUS

– PROFIsafe via PROFINET

safety

Functional safety

The following versions of MOVITRAC B are equipped with the safety function “Safe Torque Off” (STO) pursuant to EN ISO 13849-1 PL d:

– 3x AC 230 V:

- 0.55 kW to 2.2 kW: in SO design

- 3.7 kW to 75 kW: integrated as standard

– 3x AC 400 V:

- 0.55 kW to 4 kW: in SO design

- 5.5 kW to 75 kW: integrated as standard

- 1x AC 230 V: STO not available

Additional safety

– UCS..B

– BST brake module

– Safe torque off: STO

– Safe stopping: SS1/ SS2

– Safe operational stop: SOS

– Safe motion: SLA / SLS / SDI

– Safe positioning: SLP / SLI

– Safe signaling: SCA / SSM

– Safe brake control: SBC

MOVI-PLC advanced controller

Control technology – Controller performance class “advanced”:

– DHE21B/DHE41B

– MOVI-PLC advanced, Ethernet interface

– DHF21B/DHF41B

– MOVI-PLC advanced, Ethernet / PROFIBUS / DeviceNet™ interface

– DHR21B/DHR41B

– MOVI-PLC advanced, Ethernet / PROFINET/ Modbus TCP / EtherNet/IP™ interface

Engineering software MOVITOOLS MotionStudio

The MOVITOOLS MotionStudio program package allows you to conveniently start up, configure and run diagnostics for MOVITRAC B frequency inverters and MOVIDRIVE B application inverters.

Regenerative power supply MOVIDRIVE MDR60A 15 kW – 160 kW MOVIDRIVE MDR61B 160 kW – 315 kW

The regenerative power supply can supply multiple units with power using a central line connection. In regenerative mode, the power is fed back into the supply system. Using the MDR60A/MDR61B saves energy and reduces installation work.

Braking resistors type BW

BW series braking resistors are available for regenerative operation of the MOVITRAC B frequency inverters and MOVIDRIVE B drive inverters. Using an integrated temperature sensor, the resistor can be protected without external monitoring.

Line choke type ND

ND series line chokes increase the overvoltage protection of inverters. This is an important characteristic in rough industrial power supply systems, especially if the inverter is installed near a supply transformer.

Line filter type NF

The NF line filter series is available for EMC-compliant installation according to EN 61800-3. They suppress interference emission on the line side of inverters. These line filters ensure that limit value class C1 is maintained on the supply end.

Output choke type HD

HD series output chokes suppress interference emission emitted from unshielded motor cables. They enable the motor to meet limit value class C1 requirements in accordance with EN 61800-3 in EMC-compliant installations. Output chokes provide an alternative to shielded motor cables in EMC-compliant installations.

Output filter type HF

HF series output filters are sine filters that smooth out the output voltage of inverters. Output filters are used for group drives to suppress discharge currents in motor cables and for long motor cables to prevent voltage peaks.

Features

– Powerful drive inverter for dynamic applications with synchronous and asynchronous motors in the power range 0.55 to 315 kW

– Great diversity of applications due to extensive expansion options with technology and communication options

Line connection

Power range in kW

200 / 240 V / 3-phase

1.5 – 37

400 / 500 V / 3-phase

0.55 – 315

Standard design

The units are equipped with IPOSplus integrated positioning and sequence control as standard and can be expanded by the options available. “00” at the end of the type designation indicates

the standard design.

Technology version with application modules

In addition to the standard version, these units include the technology functions “electronic cam” and “internal synchronous operation”. The application version is indicated by “0T” following the type designation.

The application version units also provide access to the application modules, the standardized control programs to solve sophisticated technical drive tasks, such as synchronized applications, positioning, flying saw, and winding.

Advantages of the application modules

– High functionality and user-friendly user interface

– Only the parameters needed for the application have to be entered

– Guided parameterization instead of complicated programming

– No lengthy training or familiarization, which means quick project planning and startup

– Control of all motion functions is performed directly in MOVIDRIVE B

– Decentralized concepts can be implemented more easily

safety

Functional safety

MOVISAFE:

Integrated functional safety

Standard design Safe Torque Off (STO) PL d according to EN 13849-1

For information on operating explosion-proof motors with our inverter technology, refer to page 141.
