MOVIGEAR
Features / benefits
safety
Functional safety
– Completely integrated, compact design: Motor, gear unit and electronics are combined in a single mechatronic drive system
– The optimized system efficiency offers an energy saving potential of up to 50% and thus a reduction of the TCO due to innovative technology:
- Permanent-field synchronous motor instead of asynchronous motor
- Motor efficiency surpasses energy efficiency class IE4 (Super Premium Efficiency) of IEC 60034
- Surpasses the highest defined energy efficiency class IES2 according to EN 50598-2 for the system made of motor and electronics
- Helical gearing for extremely compact design and highest efficiency
- Electronics integrated into the motor for optimal functionality and minimal losses
- Optimized electronic components and intelligent control modes
– Overload capacity of up to 350% for high breakaway and acceleration torques prevent over- sizing in static operation and reduces the installed system power
– High degree of protection
– Worldwide use due to the large input voltage and frequency range as well as the compliance with all worldwide energy efficiency regulations
– The systematic development of all components ensures high reliability and a long service life, resulting in a high system availability
– Monitoring functions and maintenance are supported
– Quick and simple installation
– Detailed diagnostic options
– Installation topology with SEW-EURODRIVE controller:
- SNI: only one cable for power supply and communication; installation effort reduced by up to 60%
- SBus: for applications with high performance demands
– Installation topology binary or AS-Interface for easy drive functions
– Integrated functional safety: Safe Torque Off (STO) up to PL e according to EN ISO 13849-1
Verified by an independent entity: Energy saving potential of up to 50%
University of Applied Sciences of Kaiserslautern
Department of Applied Engineering Sciences
“A comparison of the test results shows a
significant efficiency advantage of MOVIGEAR drives … over the entire load range.”
Possible applications | Perfectly suitable for many industries such as beverage and food, automotive and pharmaceutical industry but also airport logistics, intralogistics in general, or construction industry. |
Performance classes and designs | MOVIGEAR is available in two sizes, three performance classes and two mechanical variants: MOVIGEAR performance classes – MGF.2 (torque class: 200 Nm, up to 0.8 kW) – MGF.4 (torque class: 400 Nm, up to 1.6 kW) – MGF.4/XT (torque class: 400 Nm with extended continuous torque, up to 2.1 kW) MOVIGEAR variants – MOVIGEAR with hollow shaft and key – MOVIGEAR with TorqLOC hollow shaft mounting system Speed setting range and positioning performance – Standard control range 1:10 – Extended control range 1:2000 - Single-turn encoder /ECR - Multi-turn absolute encoder /ACR Universal design /MU thanks to internal pressure compensation – Pressure compensation of the gear unit /PG – Pressure compensation fitting of the electronics /PE |
Design for special ambient conditions | – Meets all of the requirements for use in hygienic areas – HP200 surface treatment with optimal anti-adhering properties - ECOLAB-tested chemical and mechanical resistance - FDA approval - Minimal cleaning effort – Degree of protection IP66 – Perfectly suited for nearly all applications in clean room environments as it complies with all requirements of clean room drives up to air cleanliness class 2 according to ISO 14644-1 (confirmed by Fraunhofer Institute) – Pressure compensation fitting – Stainless steel fitting – Internal pressure compensation |
Application options MOVIGEAR with optional digital inputs and outputs | – Reading and processing of digital and analog sensor signals decentralized and close to the drive via GIO12B and GIO13B application options – Fast response to sensor signals due to decentralized processing in the drive – Reduced effort for cabling and installation GIO12B application option – 4 digital inputs – 2 digital outputs for actuator control GIO13B application option – 4 digital inputs (of which 2 can be used as primary frequency inputs) – 1 digital output – 1 analog input – 1 analog output |
